KANEXPRO

ITEM SHIPS DIRECTLY FROM MANUFACTURER. WE WILL NOTIFY YOU IF IT IS NOT AVAILABLE FOR SHIPMENT.
The KanexPro SW-HDMX44DS is an HDMI 2.0 compliant 4 input and 4 output HDMI matrixing switcher. The matrix supports a mix of both 4K and 1080p displays to be connected and operated at the same time. The built-in 4K -> 1080p down-scaler will automatically downscale a 4K HDMI video signal to 1080p to ensure compatibility and the best possible picture on all connected displays. It supports resolutions up to 4K@60Hz 4:4:4, HDR10, Dolby Vision. It can be controlled via front panel buttons, IR remote and RS232 commands.

APPLICATIONS:

This HDMI Matrixes can connect multiple sources to multiple displays. The SW-HDMX44DS features a specialized down-scaling function that allows for mixed resolution displays to show content at the best supported resolutions. This allows for 4K displays to display 4K resolutions and 1080p displays to show 1080p resolution at the same time from the same source. Ideal solution for home theater, office, school, conference room, retail, or hospitality applications.

FEATURES:
  • Supports resolutions up to 4K@60Hz 4:4:4, HDR10, Dolby Vision, including 1080p 3D.
  • Fully compliant with HDMI V2.0 and HDCP 2.2 specifications.
  • Supports 4K to1080p down-scaling for each independent output to compatibility with the legacy 1080p displays.
  • Smart EDID management.
  • Supports front panel buttons, IR remote and RS232 control.
  • Backed by KanexPro 3 -Year Parts & Labor Warranty

SPECIFICATIONS:

HDMI Performance:
  • HDMI Compliance: HDMI 2.0
  • HDCP Compliance: HDMI 2.2
  • Maximum Bandwidth: 18Gbps
  • HDMI Audio: Supports PCM, Dolby Digital and DTS.
  • HDMI Supported Resolutions: Up to 4K@60Hz 4:4:4, HDR10, Dolby Vision, including 1080p 3D.
Control:
  • Control Ports: (1) RS232, (1) IR Eye
  • Control Connector: (1) 3-pin terminal block, (1) 3.5mm jack
Video Connectors:
  • Input: (4) HDMI
  • Input Connectors: (4) Female type A HDMI
  • Output: (4) HDMI
  • Output Connectors: (4) Female type A HDMI
Operating Environment:
  • Working Temperature: -5~55°C
  • Storage Temperature: -25~70°C
  • Humidity (No Humidity): -0~90%RH
Physical Properties:
  • Dimensions: 244 x 25.5 x 100mm
  • Material: Aluminum
  • Color: Black
  • Weight: 640g
Power Supply:
  • Input Power: 12v DC 2A
  • AC Adapter Input Power: 100 to 240 V AC, 50/60 Hz
  • Power Consumption:  12 watts

Warranty:

3 Year parts and labor
